CN9132 Computer on Module

4 x Arm Cortex-A72, up to 2.2GHz

  • Up to 25Gbps packet processing and 15Gbps security performance
  • Can scale from 6 SerDes to 18 SerDes I/Os.
  • Enables fanless designs at <10W power consumption.
CN913x CEx7 block diagram 2022

CN9132 Computer on Module

SolidRun’s CEx7 CN913x Computer-on-Module based on the COM Express Type 7 form factor was designed to provide a flexible, scalable & robust networking computing module. It offers the best MIPS/power ratio for Quad Cortex A72 in the market as well as advanced support for user-space networking DPDK that transforms the platform into a high-end data plane machine.

With full virtualization capabilities, a range of connectivity options and high-end networking, the CEx7 CN9130 module is well-positioned to support SDN/NFV solutions, and a wealth of other use cases such as access point, security gateway, mini edge server and more. This module offers a highly optimized power-price-performance ratio in comparison with competing x86 based COM Express modules on the market.

Learn more about COM Express Type 7 standard.

  • Performance

    CEx7 CN9130 Computer-on-Module harnesses the robust processing power of Marvell’s OCTEON TX2 CN9130 / CN9131 / CN9132 quad core Cortex A-72 processors, with 3 x 10GbE interfaces for cutting-edge networking possibilities.

  • Modularity & Flexibility

    SolidRun’s CEx7 CN9130 COM is designed base on the popular COM Express type 7 form factor, allowing simpler development and deployment options, and simple interchangeability with future COM Express 7 based modules.

  • Software Defined Networking

    This COM module is fully supported under Linux. This provides customers the speed and agility to add, customize and integrate 3rd party software stacks.

  • Variety of Configurations

    Based on Marvell’s OCTEON TX2™ CN913X SoC fan-out configurations of CN9132, CN9131 and CN9130 several COM module types are offered. While the Processor remains the same they differ in features like 88F8215 CP Extensions, SATA Gen3, XFI/RX AUI/SGMII, PCIe Gen 3.0, USB and UART.

marvell netwoking logo bar

Related Articles

F52AFEEF 8652 432E BB0C C3E419106764.png 1030x574 1
Arm servers 1

Our Approach

To simplify development and deployment to our customers SolidRun SW R&D teams are set to provide:
– Optimized BSP.
– Stable long term support for selected distributions.
– Ongoing contributions to mainline projects and community initiatives.
All of our public source code is available on our GitHub page.

debianubuntoopenwrt
debianubuntuopenwrt 1

Where to Start?

SolidRun Developer Center is a knowledge base platform that contains hundreds of articles about topics such as getting started, product documentation and reference designs, in-depth software articles,
software development guidelines and much more.
New articles are added on a weekly basis by our hardware and software engineers.

For more information about the CN913x software section click here.

btn developerCenter 2

Always There for You

Our global technical support department will be happy to assist you, don’t hesitate to contact us!

CN9132

CN9131

CN9130

CPUMarvell OCTEON CN9132
4 x Cortex A72
Marvell OCTEON CN9131
4 x Cortex A72
Marvell OCTEON CN9130
4 x Cortex A72
CPU Speed2.2GHz Commercial
2.0GHz Industrial
2.2GHz Commercial
2.0GHz Industrial
2.2GHz Commercial
2.0GHz Industrial
RAMDual Channel
up to 32GB (16GB for each channel) DDR4
Dual Channel
up to 32GB (16GB for each channel) DDR4
Dual Channel
up to 32GB (16GB for each channel) DDR4
Internal Storage8GB eMMC
64Mb SPI
8GB eMMC
64Mb SPI
8GB eMMC
64Mb SPI
External Storage SupportNOR-Flash
SD
PCIe-SSD
NOR-Flash
SD
PCIe-SSD
NOR-Flash
SD
PCIe-SSD
Ethernet3 x 10/5 GbE port
1 x 1 GbE Port
Sync-E, 1588-V2
2 x 10/5 GbE port
1 x 1 GbE Port
Sync-E, 1588-V2
1 x 10/5 GbE port
1 x 1 GbE Port
Sync-E, 1588-V2
USB 2.022
USB 3.01
PCIe1 (Gen 3.0) X4
1 (Gen 3.0) X2
Up to 6 x (Gen 3.0) X1
1 (Gen 3.0) X4
1 (Gen 3.0) X2
Up to 3 x (Gen 3.0) X1
1 (Gen 3.0) X4
1 (Gen 3.0) X21 x USB 3.0
I2C543
SPI
UART222
GPIO
PWM
SATA2 (Gen 3.0)1 (Gen 3.0)
JTAG
Embedded LinuxLinux
DPDK
Linux
DPDK
Linux
DPDK
Size125 x 95 mm
COM Express Type 7
125 x 95 mm
COM Express Type 7
125 x 95 mm
COM Express Type 7
InterfaceCOM Express Type 7 HeadersCOM Express Type 7 HeadersCOM Express Type 7 Headers
Main Voltage12V12V12V
I/O Voltage3.3V/1.8V3.3V3.3V
TemperatureCommercial: 0°C to 70°C
Industrial: -40°C to 85°C
Commercial: 0°C to 70°C
Industrial: -40°C to 85°C
Commercial: 0°C to 70°C
Industrial: -40°C to 85°C
HumidityHumidity (non-condensing): 10% – 90%Humidity (non-condensing): 10% – 90%Humidity (non-condensing): 10% – 90%

(*) Configurable SERDESs based on Marvell CN913x processor specifications.

ClearFog CN
CX CN9132 Evaluation Board
I/Os3 x USB 3.0
3 x USB 2.0
Networking1 x SFP+ 10GbE
1 x 5GbE RJ45 (with PoE PD)
1 x 5GbE RJ45 (with PoE PSE)
1 x 1GbE RJ45 MDI
ETH SW with 4x 1GbE RJ45 ports – Optional
ProcessorMarvell OCTEON based CN9132 Quad core Arm Cortex A72 up to 2.2 GHz
Memory & StorageDual Channel up to 32GB (16GB for each channel) DDR4
MicroSD
8GB eMMC
DisplayNone
Misc.GPIO header
Indication LEDs
User Push Buttons
Development and Debug interfacesMicroUSB
MicroUSB to STM32 for management
Power12V DC Jack
PoE PD
Expansion card I/Os2 x SATA (Gen 3.0)
Up to 3 x M.2 Key-M 2240/2280 PCIe x1 (Gen 3.0)
1 x M.2 Key-M 2240/2280 PCIe x2 (Gen 3.0)
1 x PCIe x4 (Gen 3.0) Add-in
2 x M.2 Key-E 2230/5760 for WiFi Modules
1 x mPCIe
1 x M.2 Key-B 3042/3052 for LTE/5G
TemperatureCommercial: 0°C to 70°C
DimensionsPCBA: 172 x 214mm
EnclosureNone
SO DIMM product

16GB SO-DIMM DDR4 Memory

16GB DDR4 Memory for CN9132 COM

Please use the template below to create the configuration you are interested in. Since there are many options for each SOM configuration it is not possible to keep all of them in stock, for this purpose SolidRun provides off the shelf configurations with high runner part numbers, please visit our shop to review all of them.

Choose your CN913x configuration:

Part number structure
Fixed parameterCPU TypeSPIMemoryeMMCRevisionTemperatureHeatsink
SRC913XSXXDXXXEXXXV12XX
Options for parameters
Fixed parameterCPU TypeSPIMemoryeMMCRevisionTemperatureHeatsink
SRC9130 = CN9130
C9131 = CN9131
C9132 = CN9132
S64 = 64MBD00G = No DDRE000 = No eMMC
E008 = 8GB
E016 = 16GB
E032 = 32GB
E064 = 64GB
V12C = Commercial
I = Industrial
0 = No Heatsink
H = Heatsink
